High voltage/high insulation open-frame HI Series Reed Relay with high leakage distance. High Insulation Resistance (IR) >10^14 Ω.

Control systems, medical equipment, test and measurement (ATE)





Coil Voltage (VDC)	5, 12
Coil Resistance (Ω)	140-900
Contact Form	1A (SPST) Normally Open (N.O.)
Rated Power Max.	100W/1000VDC/1A



Document	File Type	File Size	Download
HI Series Datasheeet	PDF	391 KB
