Ultraminiature 8-pole low profile through hole mount (THT) RM05-8A-SP Series Reed Relay module with standard dual in-line (DIL) pin-out (2mm raster) and integrated magnetic shield for high density board mounting. Equipped with an 8-channel relay driver with MAX4823 with kickback protection and parallel activation electronics. Designed to significantly reduce PCB space at 24% smaller than our RM05-8A, saves on wiring costs, and assembly costs.
Test and Measurement, Automated Test Equipment (ATE), High Density Boards
