The 4-pole RM05-4A series is an (RF) high frequency reed relay packaged as a low profile, (SMD) surface mount reed relay module. This RF reed relay is capable of switching beyond 5.5 GHz with <40ps rise times for switching fast pulses.

High frequency (RF), telecommunications, test and measurement (ATE)





Coil Voltage (VDC)	5
Coil Resistance (Ω)	185
Contact Form	4A (4PST) Normally Open (N.O.), 2A (DPST) Normally Open (N.O.) + 2B (DPST) Normally Closed (N.C.), 2B (DPST) Normally Closed (N.C.)
Rated Power Max.	10W/170VDC/0.5A



Document	File Type	File Size	Download
RM05-4A Series Datasheeet	PDF	709 KB
