General purpose micro single in-line (SIL) MS Series Reed Relay with rugged thermoset overmolded package has a standard internal magnetic shield. This instrumentation grade relay can be stacked in close matrices. Available in high frequency version up to 1GHz. Optional diode. UL approval.

Alarm systems, computer peripherals, general purpose, telecommunications, test and measurement (ATE)





Coil Voltage (VDC)	5, 12
Coil Resistance (Ω)	280-700
Contact Form	1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.)
Rated Power Max.	10W/200VDC/0.5A



Document	File Type	File Size	Download
MS Series Datasheeet	PDF	358 KB
