General purpose dual in-line (DIL) IC compatible DIP Series Reed Relay supplied in a rugged thermoset overmolded package. Available with dielectric strength 4.25kVDC. Optional diode. UL approval.

General purpose, medical equipment, telecommunications, test and measurement (ATE)





Coil Voltage (VDC)	3, 5, 12, 15, 24
Coil Resistance (Ω)	500-2000
Contact Form	1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.), 1C (SPDT) Changeover, 2A (DPST) Normally Open (N.O.)
Rated Power Max.	50W/500VDC/2A



Document	File Type	File Size	Download
DIP Series Datasheeet	PDF	445 KB
