General purpose line sensing dual in-line DIL Series Reed Relay with coil up to 11.000 Ω. Supplied in an epoxy encapsulated package. Available with dielectric strength 4.25kVDC. Optional diode and magnetic shield. UL approval.

General purpose, medical equipment, telecommunications, test and measurement (ATE)





Coil Voltage (VDC)	5, 12, 24
Coil Resistance (Ω)	500-10000
Contact Form	1-4A Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.), 1C (SPDT) Changeover, 2A (DPST) Normally Open (N.O.), 2C (DPDT) Changeover,
Rated Power Max.	50W/500VDC/2A



Document	File Type	File Size	Download
DIL Series Datasheeet	PDF	421 KB
