The KSK-1A54 is a high frequency reed switch with glass length of 53.4mm and diameter of 5.4mm. This high frequency reed switch has a rated power 25 W, Switching voltage 500 VDC, Switching current 1.5 Amp DC.

Medical equipment, test and measurement (ATE), high power, high voltage, RF





Overall Length mm (inches)	81.6 (3.212)
Glass Length Max. mm (inches)	53.4 (2.102)
Glass Dia. Max. mm (inches)	5.40 (0.212)
Lead Dia. mm (inches)	1.3 (0.051)
Contact Form	1A (SPST) Normally Open (N.O.)
Rated Power Max.	25W/500VDC/1.5 Amp DC
