Normally closed (SPST-N.O.) surface mount (SMD) MK15 Series Reed Sensor used in On/Off control switch, proximity, motion, position detection. Supplied in tape and reel according to IEC 286/part 3. Axial or gull-wing lead, high power switch. UL Approval

Industrial, security, telecommunications, white goods





Contact Form	1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.)
Operating Range	10-60 AT
Rated Power Max.	10W/200VDC/0.5A



Document	File Type	File Size	Download
MK15 Series Datasheeet	PDF	333 KB
