Best value screw fastened flange mount MK04 Series Reed Sensor in a rectangular housing with cable terminals. Used in position, proximity, motion, level, and end limit sensing. Optional internal switch, cable, length, and termination. UL Approval

Industrial, security, white goods





Contact Form	1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.), 1C (SPDT) Changeover
Operating Range	10-60 AT
Rated Power Max.	10W/400VDC/0.5A



Document	File Type	File Size	Download
MK04 Series Datasheeet	PDF	336 KB
