SPDT Changeover surface mount (SMD) MK01 Series Reed Sensor used in On/Off control switch, proximity, motion, position detection with high power switch option. Supplied in tape and reel according to IEC 286/part 3. UL Approval

Electric vehicles, industrial, security, telecommunications, white goods





Contact Form	1A (SPST) Normally Open (N.O.), 1B (SPST) Normally Closed (N.C.), 1C (SPDT) Changeover
Operating Range	10-60 AT
Rated Power Max.	10W/200VDC/0.5A



Document	File Type	File Size	Download
MK01 Series Datasheeet	PDF	332 KB
