Our most versatile general purpose BE Series Reed Relay with many contact configuration options including up to 5 form A switches. Available in latching or high IR typical 10^13 Ω. Plastic or metal housing, epoxy encapsulated.

Battery powered devices, general purpose, medical equipment, photovoltaic, telecommunications, test and measurement (ATE)





Coil Voltage (VDC)	5, 12, 24
Coil Resistance (Ω)	140-8000
Contact Form	1-5A Normally Open (N.O.), 1-2B (SPST) Normally Closed (N.C.), 1-2C (SPDT) Changeover, 1-2E Latching/Bistable, 2A (DPST) Normally Open (N.O.) + 2B (DPST) Normally Closed (N.C.)
Rated Power Max.	100W/1000VDC/1A



Document	File Type	File Size	Download
BE Series Datasheeet	PDF	422 KB
