Features:



• Up to 16 Amp Continuous Contact Capacity
• 5 KV Dielectric Strength Between Coil and Contacts
• 1 Form A to 2 Form C Contact Forms Available
• Low Profile Design, .62 in. Tall
• Meets UL 873 Spacing
• 85°C Operating Temperature
• RoHS Compliant

Detail Specs

Operate Time	< 10 ms
Release Time	< 10 ms
Insulation Resistance	1,000 MΩ min, at 500 VDC
Dielectric Strength	5000 V, 50 Hz. between contact and coil 1000 V, 50 Hz between open contacts
Shock Resistance	98 m/s2 11ms
Power Consumption	0.4 W Single Coil, 0.6 W Dual Coil
Creepage Distance	8.4 mm
Vibration Resistance	10 - 55 Hz, DA 1.5 mm,
Terminal Strength	10N
Solderability	260 ºC for 5 seconds
Ambient Temperature Range	- 40°C to 85°C
Relative Humidity	85% (at 40°C)
Weight	13 g
