Features:



• 50 Amps Continuus Carrying Current
• Internal Diode or Resistor Option
• Sockets Available

Characteristics

Insulation Resistance	100 MΩ min. at 500 VDC
Dielectric Strength	500 Vrms, 50 Hz, between contacts 750 Vrms, 50 Hz, between coil & contacts
Power Consumption	1.6W
Terminal Strength	8N quick connect, 4N PCB pins
Operating Temperature	-40ºC to 125ºC
Storage Temperature	-40ºC to 155ºC
Shock Resistance	294 m/s2 11 ms
Vibration Resistance	10-22.3Hz; 10mm double amplitude
Weight	35.0g

Ordering Information

Documents and Downloads

Document	File Type	File Size	Download
PC792E Series Datesheet	PDF	237 KB
