Features:



• 40 Amps Continuus Carrying Current
• Internal Diode or Resistor Option
• Sockets Available
• Fully Automated Assembly

Characteristics

Insulation Resistance	100 MΩ min. at 500 VDC
Dielectric Strength	500 Vrms, 50 Hz, between contacts 750 Vrms, 50 Hz, between coil & contacts
Power Consumption	1.6W, 1.9W, 2.3W
Terminal Strength	8N quick connect, 4N PCB pins
Operating Temperature	-40ºC to 125ºC
Storage Temperature	-40ºC to 155ºC
Shock Resistance	147 m/s2 11 ms
Vibration Resistance	10-40Hz; 1.5mm double amplitude
Weight	31.0g

Ordering Information

Documents and Downloads

Document	File Type	File Size	Download
PC792A Series Datesheet	PDF	301 KB
