Ratings / Characteristics

Rating (resistive load) 25 mA at 24 VDC, 10 μA (minimum current) at 3.5 VDC
Ambient operating temperature –20 to +70°C at 60% max. (with no icing or condensation)
Ambient operating humidity 35% to 95% (at +5 to +35℃)
Insulation resistance 100 MΩ min. (at 250 VDC with insulation tester)
Contact resistance (initial value) 200 mΩ max.
Dielectric strength Between terminals 500 VAC for 1 min
Vibration resistance Malfunction 10 to 55 Hz, 1.5-mm double amplitude
Shock resistance Malfunction 300m/s2min.
Durability Electrical 1,000 operations min.
Washing Not Possible
Degree of protection IEC IP40
Operating force 0.29 to 9.8 N {30 to 1,000 gf}
Weight
Raised actuator: 0.43 g (2 poles) 0.78 g (4 poles) 1.12 g (6 poles)
1.47 g (8 poles) 1.82 g (10 poles)
