Ratings / Characteristics

Rating (resistive load) 0.1 A at 28 VDC, 1 mA (minimum current) at 5 VDC
Ambient operating temperature –10 to +70ºC 60%RH max. (with no icing or condensation)
Ambient operating humidity 45% to 85%RH (at +5 to +35°C)
Insulation resistance 10 MΩ min. (at 250 VDC with insulation tester)
Contact resistance (initial value) 200 mΩ max.
Dielectric strength Between terminals 250 VAC for 1 min
Vibration resistance Malfunction 10 to 55 Hz, 1.5-mm double amplitude
Shock resistance Malfunction 300m/s2min.
Durability Electrical 2,000 operations min.
Washing Possible
Degree of protection Internally sealed (IEC IP64)
Operating force 1.18 to 2.45 × 10−22 N·m {1.2 to 2.5 gf·m}
Weight Cone: Approx. 0.8 g
Flat: Approx. 0.7 g
Extended actuator: Approx. 0.8g
Wheel: Approx. 1.0g
