Ratings / Characteristics

Rating (resistive load) 30 mA at 30 VDC
10μA (minimum current) at 3.5 VDC
Ambient operating temperature -30 to +85 °C at 60% max. (with no icing or condensation)
Ambient operating humidity 35% to 95% (at +5 to +35℃)
Insulation resistance 100 MΩ min. (at 250 VDC with insulation tester)
Contact resistance (initial value) 200 mΩ max.
Dielectric strength Between terminals 300 VAC for 1 min
Vibration resistance Malfunction 10 to 55 Hz, 1.5-mm double amplitude
Shock resistance Malfunction 490 m/s2min.
Durability Electrical 1,000 operations min.
Washing Not Possible
Degree of protection IEC IP40
Operating force 0.29 to 4.9 N {30 to 500 gf}
Weight 0.13g (2 poles)
0.22g (4 poles)
0.3g (6 poles)
0.4g (8 poles)
0.48g (10 poles)
