Connects to a maximum of two G3PA-VD Relays.
Prevents malfunction of the G3PA-VD due to residual voltage, leakage current, or input noise.

Item	Specifications
Input voltage range	10.2 to 30 VDC
Operate time	1 ms max.
Release time	1 ms max.
Vibration resistance	10 to 55 to 10 Hz, 0.375-mm single amplitude (when mounted using screws)
Shock resistance	300 m/s^{2Storage: -30 to 100°C (with no icing or condensation) Operating: -30 to 80°C (with no icing or condensation)} (approx. 30 G)
Ambient temperature	Storage: -30 to 100°C (with no icing or condensation) Operating: -30 to 80°C (with no icing or condensation)
Ambient operating humidity	45% to 85%
Weight	Approx. 65 g

Document	File Type	File Size	Download
G32A-C Series Datasheet	PDF	282 KB
