Ratings / Characteristics

  Rated input voltage
Item 100/120 VAC 200/240 VAC
Input voltage range 75 to 132 VAC 150 to 264 VAC
Operate time 1.5 cycles max. of load power supply
Release time 1.5 cycles max. of load power supply
Vibration resistance 10 to 55 to 10 Hz, 0.375-mm single amplitude (when mounted to DIN track)
Shock resistance 300 m/s2 (Approx. 30 G)
Ambient temperature Storage: -30 to 100°C (with no icing or condensation)
Operating: -30 to 80°C (with no icing or condensation)
Ambient humidity Operating: 45% to 85%
Weight Approx. 80 g
