Model Image Description
CS series Touch Sensor Anti-vandal Switch
CS Series E-Switch Anti-vandal Switch
  • 19mm or 22mm panel cutouts
  • Latching or Momentary Function options
  • Ring or Ring/Power Symbol lens options
  • Illuminated color options - Red, Green or Blue
  • Capacitive switching technology (Touch Sensor)
PMV6 Series Anti-Vandal Switch
PMV6 Series E-Switch Anti-vandal Switch
  • 16mm panel cutout
  • UL3385 20AWG pre-stripped and tinned wire leads
  • Multiple Cap Colors
  • 10,000 Cycle Electrical Life
  • Crisp tactile response
  • IP67 rated
PV0 Series IP65 Illuminated Anti-vandal Switch
PV0 Series E-Switch Anti-vandal Switch
  • 12mm panel cutout
  • Ring or dot illumination options
  • Multiple LED color options
  • IP65 rated
PV10 Series Anti-vandal Switch
PV10 Series E-Switch Anti-vandal Switch
  • 40mm diameter panel cutout
  • Dot or ring illumination options available
  • Multiple switch functions available
  • Multiple illumination voltage options
  • IP65 rated
  • SPDT or DPDT
PV1 Series Long Life, Water Resistant Anti-vandal Switches
PV1 Series E-Switch Anti-vandal Switch
  • 19mm diameter panel cutout
  • 1 pole Off-(On) with IP65 rating
  • Solder and screw terminal options available
PV2 Series Water Resistant, Long Life Anti-vandal Switches
PV2 Series E-Switch Anti-vandal Switch
  • 16mm diameter panel cutout
  • 1 pole Off-(On) with IP65 rating
  • Solder and screw terminal options available
PV3 Series Illuminated, Sealed, Long Life Anti-vandal Switches
PV3 Series E-Switch Anti-vandal Switch
  • 16mm diameter panel cutout
  • Dot and ring illumination options available
  • 1 or 2 poles momentary functions
  • Non-sealed and sealed options configurable
PV4 Series Illuminated, Sealed, Long Life Anti-vandal Switches
PV4 Series E-Switch Anti-vandal Switch
  • 19mm diameter panel cutout
  • Dot and ring illumination options available
  • 1 or 2 poles maintained, momentary and double break functions with IP65 rating
  • RGB LED available
PV5 Series Sealed, Long Life Anti-vandal Switches
PV5 Series E-Switch Anti-vandal Switch
  • Solder terminal options available
  • 1 pole momentary switch
  • IP65 rated
PV6 Series Illuminated, Sealed, Long Life Anti-vandal Switches
PV6 Series E-Switch Anti-vandal Switch
  • 16mm diameter panel cutout
  • 1 pole Off-(On) with IP65 rating
  • Dot and ring illumination options available
  • Solder terminals
PV7 Series Anti-vandal, Illuminated, Long Life Switches
PV7 Series E-Switch Anti-vandal Switch
  • 22mm diameter panel cutout
  • Dot or ring lens options
  • Multiple LED colors
  • 1 pole double break function
  • IP65 rated
PV8 Series Illuminated, Sealed Anti-vandal Switches
PV8 Series E-Switch Anti-vandal Switch
  • 25mm diameter panel cutout
  • Dot and ring illumination options available
  • 1 or 2 poles maintained and momentary double break functions
  • IP65 rated
PV9 Series Sealed Illuminated Anti-vandal Switch
PV9 Series E-Switch Anti-vandal Switch
  • 28mm diameter panel cutout
  • Dot or ring illumination options available
  • Multiple switch functions available
  • IP66 rated, SPDT or DPDT
PVA3 Series Anti-vandal Switch
PVA3 Series E-Switch Anti-vandal Switch
  • 16mm panel cutout
  • Ring illumination option
  • Multiple LED color options
  • IP65 rated
  • Momentary or Latching functions
PVA6 Series Anti-vandal Switch
PVA6 Series E-Switch Anti-vandal Switch
  • 16mm diameter panel cutout
  • Solder lug or wire leads (500mm long) termination
  • Ring or power symbol illumination options
  • IP67 rated, Off-(On), SPST
  • Refer to Detail Specs for PVA6L - latching version
PVB3 Series Anti-Vandal Switch PVA6 Series E-Switch Anti-vandal Switch
  • 16mm panel cutout
  • Ring illumination option
  • Multiple LED color options
  • IP65 rated
  • Momentary or Latching functions
PVHC4 Series Anti-vandal Switch PVHC4 Series E-Switch Anti-vandal Switch
  • 19mm diameter panel cutout•
  • LED option
  • Ring or power symbol illumination available
  • Multiple function options
  • IP67 rated
  • SPST
PVK4 Series Key-Lock Anti-Vandal PVK4 Series
  • This new Anti-Vandal Switch features both a Keylock and Selector actuator, including multiple 2 - 3 positions with Maintained (IP65) and Return (IP40) functions, making it an incredibly versatile switch.
PVL Series Pilot Lamp Indicator
PVL Series E-Switch Anti-vandal Switch
  • Pilot lamp indicator
  • IP67 rated
  • Multiple panel cutout sizes ranging from 6mm to 19mm
  • Mulitple illumination volt options
  • Multiple LED color options
  • 40,000 hours nominal lamp life
  • 150mm long wire lead option
PVP Series Anti-vandal Switch Socket
PVP Series E-Switch Anti-vandal Switch
  • PVP3 both socket and wired socket are compatible with PV3 series switches featuring SPDT, DPDT, non-illuminated, or LED illuminated color options.
  • PVP4 both socket and wired socket are compatible with PV4 series switches featuring SPDT, DPDT, non-illuminated, or LED illuminated color options.
  • PVP7 both socket and wired socket are compatible with PV7 series switchs featuring DPDT, non-illuminated, or LED illuminated color options.
  • PVP8 wired socket is compatible with PV8, PV9 and PV10 series switches featuring SPDT, DPDT, non-illuminated, or LED illuminated color options.
  • Wire, 22 AWG AWM UL 1007
  • Standard wire length 140.0mm [5.5 in]
PVS7 Series Anti-vandal Switch
PVS7 Series E-Switch Anti-vandal Switch
  • 22mm diameter panel cutout
  • Wire leads available
  • RGB LED option
  • Ring illumination avaliable
  • Multiple function options
  • IP65 rated
  • SPDT & DPDT
  • Soldered wire leads (300mm long) optional
PVT4 Series Illuminated, Tactile Response Anti-vandal Switch
PVT4 Series E-Switch Anti-vandal Switch
  • 19mm panel cutout
  • Solder lug or wire lead termination options
  • Ring illumination
  • LED color options
  • Crisp tactile response
  • IP65 rated
SAV4 Series Anti-Vandal Switch
SAV4 Series E-Switch Anti-vandal Switch
  • 19mm diameter panel cutout
  • Dot, ring, power, or ring/power illumination options
  • Multiple illumination voltage options
  • Momentary and latching functions
  • 15A high current rating
SAV7 Series Anti-Vandal Switch
SAV7 Series E-Switch Anti-vandal Switch
  • 22mm diameter panel cutout
  • Ring or ring/power illumination options
  • Multiple illumination voltage options
  • Momentary and latching functions
  • 15A high current rating
SAV8 Series Anti-Vandal Switch
SAV8 Series E-Switch Anti-vandal Switch
  • 25mm diameter panel cutout
  • Ring or ring/power illumination options
  • Multiple illumination voltage options
  • Momentary and latching functions
  • 15A high current rating
SV4 Series Anti-Vandal Switch
SV4 Series E-Switch Anti-vandal Switch
  • Short body design
  • 19mm diameter panel cutout
  • Ring or Ring/Power Symbol combo illumination
  • IP67
  • SPST
  • Optional soldered wire leads (500mm long)
SV7 Series Anti-Vandal Switch
SV7 Series E-Switch Anti-vandal Switch
  • Short body design
  • 22mm diameter panel cutout
  • Ring or Ring/Power Symbol combo illumination
  • IP67
  • SPST
  • Optional soldered wire leads (500mm long)
SV8 Series Anti-vandal Switch
SV8 Series E-Switch Anti-vandal Switch
  • Short body design
  • 25mm diameter panel cutout
  • Multiple LED options
  • Ring or Ring/Power Symbol combo illumination
  • IP67
  • SPST
  • Optional soldered wire leads (500mm long)
ULV4 Series Anti-vandal Switch UL Listed
ULV4 Series E-Switch Anti-vandal Switch
  • Dot, ring or power symbol illuminated
  • IP67 rated, UL certified
  • Long life; latching or momentary
  • Three wire lead options available:
    • 300mm long wire leads
    • Detachable socket with wire leads 500mm long
    • Molded Back with wire leads 500mm long
ULV7 Series Anti-vandal Switch UL certification and IP67 rated
ULV7 Series E-Switch Anti-vandal Switch
  • Ring illuminated, 22mm panel cutout
  • IP67 rated, UL Certified
  • Long life; latching or momentary
  • SPDT or DPDT with multiple functions
  • Three wire lead options available:
    • 300m long wire leads
    • Detachable socket with wire leads 500mm long
    • Molded Back with wire leads 500mm long
ULV8 Series UL Certified Sealed Anti-vandal Switch
ULV8 Series E-Switch Anti-vandal Switch
  • Ring illuminated, 25mm panel cutout
  • IP67 rated, UL Certified
  • Long life; latching or momentary
  • SPDT or DPDT with multiple functions
  • Three wire lead options available:
    • Wire Leads 300mm long
    • Detachable Socket with wire leads 500mm long
    • Molded Back with wire leads 500mm long
