Features

• Top performance for high speed networking, voice, and data applications
• Meets FCC Part 68, Subpart F requirements
• Advanced EMI/RFI protection with grounding options (PCB or Panel)
• v
• RoHS Compliant

Specifications

Housing Material	PBT or Nylon
Contact Material	Phosphor Bronze
Contact Plating	Gold plating on contact area and tin plating on tails with nickel underplating all over
Current Rating	1.5A @25°C
Voltage Rating	125V AC
Contact Resistance	20 mΩ maximum
Dielectric Withstanding Voltage	1000V AC
Insulation Resistance	500 MΩ minimum
Durability	750 cycles minimum
Operating Temperature	-40°C to +85°C
Wave Soldering Process	260°C ± 5°C, 5~10 Seconds

Documents and Downloads

Document	File Type	File Size	Download
J96 Series Datesheet	PDF	aaa KB
