Coil Voltages: 6, 12, 24, 110 VDC (Other voltages available upon request)
Power: 23 Watts continuous, 58 Watts intermittent, 230 Watts pulse
Coil Termination: Wire leads standard
Insulation Class: Class A Rating – 105ºC (221ºF) standard | 130ºC (266ºF) optional
Dielectric Strength: 30 volts and under, 500 VRMS | Over 30 volts, 1000 VRMS plus 2X rated voltage for 1 minute
Size (l,w,h): 3.540 x 1.750 x 1.940” [89.9 x 44.5 x 49.3]
Plunger Diameter: Ø0.63" [Ø15.9]
Plunger Guide Material: Plastic
Mounting: 12x #8-32 UNC-2B tapped holes
Life Expectancy: 250,000 cycles – dependent on application conditions
