Coil Voltages: 6, 12, 24, 110 VDC (Other voltages available upon request)
Power: 11 Watts continuous, 27 Watts intermittent, 110 Watts pulse
Coil Termination: 0.187” QC terminals standard | 0.250” QC terminals optional
Coil Treatment: Plastic encapsulated
Insulation Class: Class A Rating – 105ºC (221ºF) standard | 155ºC (311ºF) optional
Dielectric Strength: 30 volts and under, 500 VRMS | Over 30 volts, 1000 VRMS plus 2X rated voltage for 1 minute
Size (l,w,h): 1.737 x 1.437 x 1.626” [44.1 x 36.5 x 41.3]
Plunger Diameter: Ø0.50" [Ø12.7]
Plunger Guide Material: Plastic
Mounting: 8x #8-32 UNC-2B tapped holes
Life Expectancy: 250,000 cycles – dependent on application conditions
