Coil Voltages: 6, 12, 24, 110 VAC (Other voltages available upon request)
Power: 4.2 Watts continuous, 9.6 Watts intermittent, 40 Watts pulse
Coil Termination: 0.110” QC terminals standard
Coil Treatment: Plastic encapsulated
Insulation Class: Class A Rating – 105ºC (221ºF) standard
Dielectric Strength: 30 volts and under, 500 VRMS | Over 30 volts, 1000 VRMS plus 2X rated voltage for 1 minute
Size (l,w,h): 1.130 x 0.750 x 0.750” [28.7 x 19.1 x 19.1]
Plunger Diameter: Ø0.25" [Ø6.4]
Plunger Guide Material: Plastic
Mounting: 2x #4-40 UNC-2B tapped holes
Life Expectancy: 250,000 cycles – dependent on application conditions
| Document | File Type | File Size | Download |
| Datasheet | 567 KB |  |
 |
 |
 |
