Coil Voltages: 6, 12, 24, 110 VDC (Other voltages available upon request)
Power: 8 Watts continuous, 19 Watts intermittent, 80 Watts pulse
Coil Termination: 0.187” QC terminals standard
Coil Treatment: Plastic encapsulated
Insulation Class: Class A Rating – 105ºC (221ºF) standard | 155ºC (311ºF) optional
Dielectric Strength: 30 volts and under, 500 VRMS | Over 30 volts, 1000 VRMS plus 2X rated voltage for 1 minute
Size (l,w,h): 1.851 x 0.938 x 1.190” [47.0 x 23.8 x 30.2]
Plunger Diameter: Ø0.31" [Ø7.9]
Plunger Guide Material: Plastic
Mounting: 4x #6-32 UNC-2B tapped holes
Life Expectancy: 250,000 cycles – dependent on application conditions
