Description



The 2410SA is a delay on make timer controlling a DPDT set of relay contacts. The 2410SA is available in a range of both AC and DC models. With operating voltage applied, the timer starts the time delay. At the end of the timing period the output relay energizes. The 12 position DIP switches allow for selection of time range and time period.



Type	Function	Industries
Timer	Delay On Make	HVAC, General Machinery

Specifications

Timing Mode	Delay on make
Operating Voltage	12, 24V DC or 24, 115V AC.
Adjustable Timing Ranges	0.1 - 102.4 seconds, 1 - 1024 seconds, 1 - 1024 minutes, 1 - 1024 hours.
Purchase Tolerance	±2%
Repeatability Of Timing Periods	Better than ±2%
Timing Temperature Coefficient	Better than ±0.1% °C
Output Relay	DPDT contacts - 12A at 125V AC UL E88991 & CSA LR90143, 10A 125V AC TUV R9452021.
Terminations	Octal plug-in type.
Dielectric Strength	750V rms between open contact sets, 1,500V rms between contacts and operating voltage terminals.
Transient Protection	Protected by silicon transient suppressors responding to transients within 1x10-12 seconds to a peak pulse power dissipation of 1500 watts.
Operating Temperature	-20°C to 65°C
