• 150W carrying power at 2GHz
• Excellent high frequency characteristics up to 6GHz

  High frequency characteristics (to 6 GHz)		to 1 GHZ	1 to 2 GHZ	2 to 3 GHz	3 to 6 GHz
  	V.S.W.R (Max.)	1.1	1.15	1.2	1.3
  	Insertionloss (without D.U.T. board's loss, dB, Max.)	0.1	0.12	0.15	0.5
  	Isolation (dB, Min.)	60	55	45	30

• Compact dimensions and surface mount (SMD)
• 9.6 (L) x 14.6 (W) x 10 (H) mm





• Base stations (transmitter function)
• Measurement equipment
• High frequency amplifier switching in wireless devices



Document	File Type	File Size	Download
Datasheet	PDF	487 KB
