Features



High breakdown voltage - Achieves breakdown voltage between open contacts of 1,500 V AC on a 6,000 V surge breakdown voltage model.



• Surge breakdown voltage between open contacts: 1,500 V 10 x 160 µsec. (FCC part 68)
• Surge breakdown voltage between contact and coil: 6,000 V 1.2 x 50 µsec. (EN60950)



Approved to the supplementary insulation class in the EN standards (EN60950). (Clearances: 2.0 mm 0.079 inch or more. Creepage distance: 2.5 mm 0.098 inch or more.)



Applications



• Facsimile
• Modem
• Communications (xDSL)
• Medical equipment
• Automotive equipment
• Security
