Features



• Low profile type with height of 15.7 mm (0.618 inch)
  • 28.8 (L) x 12.5 (W) x 15.7 (H) mm,
  • 1.134 (L) x 0.492 (W) x 0.618 (H) inch
• High insulation resistance - Superior insulation characteristics have been achieved by maintaining an insulation distance between coil and contacts of at least 10mm for both creepage distance and clearances.
• Superior heat resistance - Can be used in ambient temperature up to 85°C (185°F) for the class B and 105°C (221°F) for the class F.
• Conforms to the various safety standards - UL, C-UL, VDE approved.
• Superior heat resistance and tracking resistance - EN60335-1 GWT compliant (Tested by VDE) type available. (Class B insulation type only).



Applications



• Household electrical appliances - Audio equipment and heaters, etc.
• Office equipment - Copy machines, air conditioners, and vending machines
• Industrial equipment - Machine tools, robots, and temperature controllers.



Document	File Type	File Size	Download
Datasheet	PDF	73 KB
