Typical Specifications

Rating（max.）/（ min.）（Resistive load） 0.3A 5V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 70mΩ max. / 130mΩ max.
Operating force Refer to the dimensions.
Operating life Without Load 10,000 cycles 100mΩ max.
With Load 10,000 cycles 130mΩ max. （0.3A 5V DC）

Downloads

Document File Type File Size Download
SSSS8 Series Datasheet PDF 1.2 MB
