Typical Specifications

Rating(max.)/( min.)(Resistive load) 10mA 5V DC / 50μA 3V DC
Contact resistance (Initial / After operating life) 200mΩ max. / 500mΩ max.
Operating force 1N( Recoil side) 1.5N( Lock side)
Operating life Without Load 100,000 cycles( Recoil side) 30,000 cycles( Lock side)
With Load 100,000 cycles( Recoil side) 30,000 cycles( Lock side()10mA 5V DC)

Downloads

Document File Type File Size Download
SSAG Series Datasheet PDF 1.2 MB
