Typical Specifications

Rating（max.）/（ min.）（Resistive load） 1mA 5V DC/50μA 3V DC
Contact resistance （Initial / After operating life） 100mΩ max./200mΩ max.
Operating force 2-position 3-position
2.5±1.5N a, c → b 2±1.5N
b → a, c 2.5±1.5N
Operating life Without Load 10,000 cycles
With Load 10,000 cycles（ 1mA 5V DC）

Downloads

Document File Type File Size Download
SSAC Series Datasheet PDF 938 KB
