Typical Specifications

Rating（max.）/（ min.）（Resistive load） 0.25A 30V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 20mΩ max. / 60mΩ max.
Rotational torque Shorting 80±30mN･m
Non-Shorting 70±30mN･m
Operating life Without load 10,000 cycles
With Load 10,000 cycles（ 0.25A 30V DC）

Downloads

Document File Type File Size Download
SRRM Series Datasheet PDF 974 KB
