Typical Specifications

  Rotary switch Pulse switch
Rating（max.）/（ min.）（Resistive load） 0.1A 16V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 50mΩ max. / 150mΩ max.
Rotational torque 40±20 mN・m 15±7 mN・m
Operating life Without Load 10,000 cycles 20,000 cycles
With Load 10,000 cycles（ 0.1A 16V DC）

Downloads

Document File Type File Size Download
SRBM Series Datasheet PDF 925 KB
