Typical Specifications

Rating（max.）/（ min.）（Resistive load） 1mA 5V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 200mΩ max. / 250mΩ max.
Rotational torque 13±5mN･m
Operating life with load 10,000 cycles（ 1mA 5V DC）
Voltage proof 100V AC 1minute

Downloads

Document File Type File Size Download
SRBD Series Datasheet PDF 983 KB
