Typical Specifications

  Standard Medium-current
Rating （ max.）/（min.） （Resistive load） 0.1A 30V DC 50μA 3V DC 1A 25V DC
Contact resistance （Initial / After operating life） 20mΩ max. / 40mΩ max.
Operating force 2-pole 2±1N 3±1.5N
4-pole 2.5±1N 4±2N
Operating life Without Load 30,000 cycles 10,000 cycles
With Load 10,000 cycles
（0.1A 30V DC）		 5,000 cycles
（1A 25V DC）
