Typical Specifications

Rating（ max.）（/ min.） （Resistive load） 0.2A 30V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 20mΩ max. / 40mΩ max.
Operating force 1-pole 2.3±1N
2-pole 3.3±1N
Operating life Without Load 10,000 cycles
With Load 10,000 cycles（ 0.2A 30V DC）

Downloads

Document File Type File Size Download
SPPJ3 Series Datasheet PDF 1.1 MB
