Typical Specifications

Rating（ max.）（/ min.） （Resistive load） 0.2A 30V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 20mΩ max. / 40mΩ max.
Operating force 3±1.5N
Operating life Without load 10,000 cycles
With load 10,000 cycles（ 0.2A 30V DC）

Downloads

Document File Type File Size Download
SPPJ2 Series Datasheet PDF 1.1 MB
