Typical Specifications

Rating（ max.）（/ min.） （capacitor load） 50mA 16V DC / 10μA 1V DC
Contact resistance （Initial / After operating life） 200mΩ max. / 400mΩ max.
Operating force 1.96N, 2.45N, 3N
Operating life Without load 100,000 cycles
With Load 100,000 cycles（ 50mA 16V DC）

Downloads

Document File Type File Size Download
SPEH Series Datasheet PDF 795 KB
