Typical Specifications

Rating（ Resistive load） 1A 14.5V DC / 50μA 3V DC
Contact resistance （Initial / After operating life） 100mΩ max. /1Ω max.
Operating force 3N, 5N
Operating life（ With load） 30,000 cycles（ 1A 14.5V DC）
Circuit configuration 1-pole, 2-position

Downloads

Document File Type File Size Download
SPEF Series Datasheet PDF 1.0 MB
