Typical Specifications

Rating(max.)(/ min.) (Resistive load) 0.1A 12V DC / 100μA 5V DC
Contact resistance (Initial / After operating life) 500mΩ max. / 1Ω max.
Operating force 2N max.
Lever devoted angle 40°
Operating life Without load 100,000cycles
With load 100,000cycles(0.1A 12V DC)

Downloads

Document File Type File Size Download
SSCN Series Datasheet PDF 752 KB
