Typical Specifications

  Standard type With internal resistor type
Rating(max.)(/ min.) (Resistive load) 0.1A 12V DC/50μA 5V DC Respond individually
Contact resistance (Initial / After operating life) 500mΩ max./1Ω max(. Standard type)
500mΩ max./3Ω max(. Long-life type
Electrical output —
Operating force Push 1±0.5N Actuator type 3N max. 1±0.5N
Operating life Without load 300,000cycles(Standard type) 1,000,000cycles(Long-life type 300,000cycles
With load 300,000cycles(Standard type) 1,000,000cycles(Long-life type) Respond individually
