Typical Specifications

  Standard type With internal resistor type
Rating(max.)(/ min.) (Resistive load) 0.1A 12V DC/ 50μA 5V DC Respond individually
Contact resistance (Initial / After operating life) 500mΩ max./1Ω max.
Electrical output - -
Operating force Push type Actuator type
1±0.5N 3N max.
Operating life Without load 300,000cycles
With load 300,000cycles （0.1A 12V DC） Respond individually

Downloads

Document File Type File Size Download
SPVQ6 Series Datasheet PDF 1.1 MB
