Typical Specifications

Rating(max.)(/ min.) (Resistive load) 0.1A 12V DC/ 50μA 5V DC
Contact resistance (Initial / After operating life) 500mΩ max. / 1Ω max.
Operating force Push type 1±0.5N Actuator type 3N max.
Operating life Without load 300,000cycles
With load 300,000cycles（0.1A 12V DC）
Poles 1
Changeover timing Non shorting
