Typical Specifications

Total resistance tolerance ±20％
Maximum operating voltage 50V AC
Total rotational angle 300°±5°
Rotational torque 10 to 40mN・m
Operating life 15,000 cycles
Operating temperature range −10℃ to ＋70℃
Motor voltage 4 to 6V DC（ Standerd：4.5V DC）
Potentiometer rotational speed（ sec./300°） 12±3（ 4.5V DC）
Maximum operating current At rotation：100mA
At end slip：150mA

Downloads

Document File Type File Size Download
RK168 Series Datasheet PDF 1.5 MB
