Typical Specifications

Total resistance tolerance ±30％
Maximum operating voltage 50V AC, 5V DC
Total rotational angle 300°±5° (Effective electrical rotational angle : 60°±5°
Rotational torque 5mN・m max.
Operating life 1,000,000 cycles
Operating temperature range −10℃ to ＋70℃

Downloads

Document File Type File Size Download
RK09Y11L Series Datasheet PDF 689 KB
