Typical Specifications

Total resistance tolerance ±20％
Maximum operating voltage 50V AC, 20V DC
Total rotational angle RK09K: 280°±5°
RK09D: 300°±5°
Rotational torque 1 to 8mN・m
Operating life 5,000 cycles
Operating temperature range −10℃ to ＋70℃

Downloads

Document File Type File Size Download
RK09K/RK09D Series Datasheet PDF 1.4 MB
