Typical Specifications

Total resistance tolerance ±30％
Maximum operating voltage 50V AC 20V DC（ Single-unit only）
Total rotational angle 200°±10°
Rotational torque 1 to 10mN・m
0.5 to 10mN・m（ Reflow type）
Operating life Without detent　10,000 cycles
With detent　 5,000 cycles
Operating temperature range −10℃ to ＋60℃

Downloads

Document File Type File Size Download
RK08H Series Datasheet PDF 848 KB
