Firm operating feel and high robustness suitable for integrated control inside vehicles.



• Two-shaft multi control device with 8-direction, center push and rotary operation.
• Rotary control of outer shaft employs a ring encoder (EC40A) for a comfortable, soft torque feel.
• LED built into the inner shaft enables illumination of text or markings.
• Use of an output harness allows easy installation.

• Integrated control of car navigation, audio and air conditioning etc.

Dimensions (W×D×H)	67.0 x 61.0 x 53.0mm
Rating	10mA 5V DC
Operating temperature	-40 to +85 ℃



	Center push	8-direction
Operating force	3.0 N	3.5 N
Travel	1.4mm (SW ON)	3mm (Top of shaft)
Operating life	100,000 cycles	30,000 cycles for each direction



	Rotary
Detent torque	0.04 N・m
Number of detents	30 detents
Operating life	30,000 cycles



Document	File Type	File Size	Download
Datasheet	PDF	138 KB
