High-efficiency power inductor ideal for PC required long battery life.



• Adopt Liqualloy™, a low-loss material developed by Alps
• Low core loss even in high-frequency switching operations
• Narrow DCR tolerance
• Optimized for high currents (low DCR)
• Contributes to smaller and more efficient power supplies

• DC/DC converters for notebook PCs and servers, etc.
• Point-of-load (POL) power supplies

Product No.		GLMHR1103A	GLMHR2303A
Inductance (μＨ) at 100kHz		0.11 ± 20%	0.23 ± 20%
Direct Current Resistance(mΩ)		0.57 ± 5%	1.10 ± 5%
Rated Current	Saturation Current △L/L=30%(A)max.	25	18
	Heat Rating Current △T=40℃ (A)max.	28	22



Document	File Type	File Size	Download
Datasheet	PDF	1.28 MB
